Product overview

* See face recognition using the world’s leading dynamic face detection tracking recognition algorithm based on video streaming, combined with high-performance embedded platform and 2 million pixel camera, accurate face detection, tracking, recognition;
* Support 1:N face comparison or 1:1 face comparison, dynamic binocular + living detection anti-counterfeiting, completely solve all kinds of photos and video fraud;
* 1: N mode can recognize 5 people at the same time. In a good light environment, the face can be recognized as far as 3 meters away. The face comparison time is about 0.1ms, and it has good anti-changeover performance against light and wearing glasses.
* The comparison time of 1:1 mode is about 0.5ms, and the threshold (50-80) can be adjusted.
* Rich hardware interfaces: Weigen, relay switch output, RJ45 network port (WiFi and 4G optional) communication;
* Perfect software functions: equipment management, personnel/face management, rights management, record view. Interface can be provided for secondary development.

Smart hardware

  • 3.5 inch screen face recognition access control
  • 5 inch screen face recognition access control
  • 7 inch screen face recognition access control
  • 7 inch screen column face recognition access control
  • 7 inch screen 4G face recognition access control
  • 4G face two-dimensional code visitor access control

  •  3.5 inch face recognition machine



    size：105*108*23mm

    Material: ABS waterproof material

    power：DC12V/3A

    storage:   10,000 faces, 100,000 records

    Read the card：IC

    model：Y3

    Open the door: IC card, face, : mobile phone Bluetooth, remote, WeChat door, two-dimensional code door


  • 5 inch face recognition machine

    Size: 192 * 90 * 23 mm

    Material: ABS.

    Power supply: DC12V / 3 a

    Camera: 1920*1080

    Screen: 800 * 480

    Storage: 10,000 faces, 100,000 records

    The card read: ID/IC

    system:Linux

    Model: FV05S

    Communication: wired network (10M/100M adaptive Ethernet port) or wireless network (4G)

    Interface: Relay output (NO, NC, COM), Wegan output (W26/W34)

    Open the door: ID/IC card, face, mobile APP or small program can: mobile phone Bluetooth, remote, WeChat door, two-dimensional code door



  • 7 inch screen face recognition access control


    Dimensions: 150*230*24mm (without support)

    Body technology: Space aluminum IP65 class waterproof

    Operating temperature: -10℃-50℃

    Installation: gate installation, wall-mounted installation

    Power supply: DC12V / 3 a

    Storage: 10,000 faces, 100,000 records

    The card read: ID/IC

    System:Linux

    Model: FV07S

    Communication mode: LAN or 4G

    Open the door: ID/IC card, face,

    Mobile APP or small program: Bluetooth, remote, WeChat door, QR code door


  • 7 inch screen column face access control


    View size: 150*230*24mm (without support)

    Body technology: Space aluminum IP65 class waterproof

    Operating temperature: -10℃-50℃

    Installation: gate installation, wall-mounted installation

    Power supply: DC12V / 3 a

    Storage: 10,000 faces, 100,000 records

    The card read: ID/IC

    System:Linux

    Model: FV07S

    Communication mode: LAN or 4G

    Open the door: ID/IC card, face,

    Mobile APP or small program: Bluetooth, remote, WeChat door, QR code door



  • 7 inch screen, 4G face access control


    View size: 150*230*24mm (without support)

    Body technology: Space aluminum IP65 class waterproof

    Operating temperature: -10℃-50℃

    Installation: gate installation, wall-mounted installation

    Power supply: DC12V / 3 a

    Storage: 10,000 faces, 100,000 records

    The card read: ID/IC

    System:Linux

    Model: FV07S - 4 g

    Communication mode: LAN or 4G

    Open the door: ID/IC card, face recognition,

    Mobile APP or small program: Bluetooth, remote, WeChat door, QR code door


  • 4G face recognition two-dimensional code visitor access control


    Size: 192 * 90 * 23 mm

    Material: ABS.

    Power supply: DC12V / 3 a

    Camera: 1920*1080

    Screen: 800 * 480

    Storage: 10,000 faces, 100,000 records

    The card read: ID/IC

    System:Linux

    Model: FV05S - 4 g/QR

    Communication: wired network (10M/100M adaptive Ethernet port) or wireless network (4G)

    Interface: Relay output (NO, NC, COM)

    Open the door: ID/IC card, face,

    Mobile APP or small program can: mobile phone Bluetooth one-button door, remote door, WeChat scan

    Open the door, scan the QR code to open the door, and open the QR code for limited time and time visitors


Product advantage

  • Cloud Platform Management

    Face recognition access control, two-dimensional code cloud access control, mobile phone access control management, visitor access control management system and other products using cloud platform management, cloud storage, cloud backup

  • Web + program

    The management system uses Web terminal + small program management. Administrators manage devices and users through Web software. Users can use the small program "Xi Liankan" to achieve mobile phone Bluetooth door, remote door, two-dimensional code door.

  • Hardware diversification

    Xi see technology to create a variety of products: classic cloud access control, delicate cloud access control, face access control, two-dimensional code access control and so on, to meet the wisdom of the community, the wisdom of the park, construction sites, agencies, chain stores all kinds of scene applications.
